Rockwell Automation FlexPak 3000 Power Module SW-Version 4.3 User Manual
Page 185
APPENDIX E
49’1340 e
FlexPak 3000
E-1
Program Error Messages and Fault and Alarm Codes
This appendix lists all possible OIM error messages generated by the drive and fault/alarm codes.
The error messages appear on the OIM display when certain drive conditions exist. Table E-1 lists fault
codes and Table E-2 lists alarm codes. Tables E-1 and E-2 list fault and alarm codes by number (Fxxxxx
= Fault; Axxxxx = Alarm), associated message visible at the OIM display and a description along with
possible causes.
