Rockwell Automation FlexPak 3000 Power Module SW-Version 4.3 User Manual
Page 80
TROUBLESHOOTING/DIAGNOSTICS
FlexPak 3000 49’1340
e
7-8
7.7.7
Power Supply Test Pin Identification
The following table lists the power supply PC board test pins and their respective voltage levels.
Since it is a switching power supply, all checks need to be made while load is connected to the
power supply card.
Test Pin
Voltage Level
J4 to J5
J6 to J7
J8 to J7
J9 to J10
J11 to J12
J13 to J12
J14 to J16
J15 to J16
J3 to J16
+ 24 VDC
+ 12 VI
- 12 VI
+ 18 V
+ 15 VI
- 15 VI
+ 15 V
+ 5 V
- 15 V
