APPENDIX B
49’1340 e FlexPak 3000 B-7
ANLG OUT 2 SELECT (P.421)
Only available if the I/O Expansion Kit is installed.
Selects the signal used to drive analog output 2 (terminals 56 and 57 on the I/O Expansion board). When
the analog output is at its maximum value, the selected signal is at is full scale value.
Parameter Range: See table below for parameter options.
Default Setting: ZERO
Parameter Type: Configurable
OIM Menu Path(s): Input/Output - Analog I/O
Refer also to Parameters: MAXIMUM CURRENT (P.007) MOTOR HOT FLD AMPS (P.510)
MOTOR RATED ARM AMPS (P.008)
MOTOR RATED ARM VOLTS (P.009) TOP SPEED (P.011)
Signal Selected Full Scale Value
CML FEEDBACK (P.397)
CML REFERENCE (P.396)
CML ERROR (P.398)
SPD LOOP OUTPUT (P.299)
±
MOTOR RATED ARM AMPS * MAXIMUM CURRENT
100
SPD LOOP FEEDBACK (P.296)
SPD LOOP REFERENCE (P.295)
SPD LOOP ERROR (P.297)
SPEED RAMP OUTPUT (P.199)
SPEED RAMP INPUT TP (P.198)
SPD SOURCE SELECT OUT (P.193)
TRIM OUTPUT (P.197)
ANALOG TACH FEEDBACK (P.291)
PULSE TACH FEEDBACK (P.292)
OCL OUTPUT (P.848) ±
TOP SPEED
ARMATURE VOLTAGE (P.289)
±
MOTOR RATED ARM VOLTS
POWER OUTPUT ±
MOTOR RATED ARM VOLTS * MOTOR RATED ARM AMPS * MAXIMUM CURRENT
100
FIELD REFERENCE (P.590)
FIELD FEEDBACK (P.589) MOTOR HOT FLD AMPS
OCL REFERENCE (P.845)
±
4095
OCL RAMP OUTPUT (P.846)
OCL FEEDBACK (P.847)
NETW IN REG 1 (P.905)
NETW IN REG 2 (P.906)
NETW IN REG 3 (P.907)
FULL SCALE
ZERO 0
ARM VOLTAGE GAIN ADJ (P.204)
Used to scale the armature voltage signal after it has been conditioned by the drive hardware.
In most cases, this input will be 1.000.
Parameter Range: 0.750 to 1.250
Default Setting: 1.000
Parameter Type: Tuneable
OIM Menu Path(s): Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Feedback
WARNING
The incorrect setting of this parameter can cause an overspeed condition. This parameter must be set
by a qualified person who understands the significance of setting it. Set the value of this parameter
accurately per your application requirements. Failure to observe this precaution could result in bodily
injury.
