INSTALLATION AND WIRING
FlexPak 3000 49’1340 e 3-18
. Recommended Lugs for Grounding FlexPak 3000 Drives in UL / cUL Version
The following describes how to interpret Reliance USA lug model numbers used in grounding the
FlexPak 3000 drive.
The lugs are non-insulated screw type (solderless) for use with solid and stranded wire.
1LG 1 2 03
Basic Catalog Number
Number of Conductors
1 = one conductor
2 = two conductors
3 = three conductors
Mounting Hole and Lug Material
1 = one mounting hole, copper
2 = one mounting hole, aluminum
3 = two mounting holes, copper
4 = two mounting holes, aluminum
5 = four mounting holes, copper
6 = four mounting holes, aluminum
Lug Version Number
01 to 99
Table 3-7: Recommended Lugs for different Wire Sizes
RA Dierikon
Part Number Reliance USA
Model Number Reliance USA
Part Number Wire Size Mounting
Hole Material
916.10.70 1LG1101 68321-38AA 14 - 8 AWG M5 copper
916.10.71 1LG1102 68321-38AB 14 - 8 AWG M6 copper
916.10.72 1LG1103 68321-38AC 4 - 1/0 AWG M10 copper
916.10.73 1LG1104 68321-38AD 1/0 - 4/0 AWG M12 copper
916.10.74 1LG1105 68321-38AE 4/0 - 500 MCM M10 copper
916.10.80 1LG1201 68321-38BA 14 - 1/0 AWG M6 aluminum
916.10.81 1LG1202 68321-38BB 14 - 2/0 AWG M6 aluminum
916.10.82 1LG1203 68321-38BC 6 - 250 MCM M8 aluminum
916.10.83 1LG1204 68321-38BD 6 - 300 MCM M6 aluminum
916.10.84 1LG1205 68321-38BE 6 - 350 MCM M10 aluminum
916.10.85 1LG1206 68321-38BF 4 - 500 MCM M10 aluminum
916.10.86 1LG1207 68321-38BG 300 - 800 MCM M12 aluminum
916.10.87 1LG1208 68321-38BH 500 - 1000 MCM M12 aluminum
916.10.88 1LG2401 68321-39BA 2 - 600 MCM M10 aluminum
916.10.89 1LG2402 68321-39BB 350 - 800 MCM M10 aluminum
916.10.90 1LG2403 68321-39BC 500 - 1000 MCM M12 aluminum
916.10.91 1LG3601 68321-40BA 2 - 600 MCM M12 aluminum
