The amplitude and rate limited value of the selected CML reference.
OIM Menu Path(s): Current Minor Loop (CML) - CML Test Points
CURRENT COMPOUND TP (P.293)
An output testpoint that represents the current compounding value to be used by the drive.
OIM Menu Path(s): Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Test Points
DIG IN 0 (P.490)
Only available if the CS3000 Software or the AMX Network communication card is installed.
Indicates the state of digital input 0 based on the voltage applied.
Parameter Range: ON
OFF
Default Setting:
N/A
Refer also to Parameters: JOG SPEED 1 (P.012)
JOG SPEED 2 (P.017)
All digital inputs are normally open, thus will be OFF when open or connected to 24V COM (TB-15) and
ON when +24V (TB-14) is applied.
Conditions Indicated by DIG IN 0 (P.490)
DIG IN 0 SELECT (P.428) Condition if DIG IN 0 (P.490) Reads:
Setting ON OFF
1 = BRUSH WEAR INPUT Brushes OK Brushes Worn
2 = JOG SPEED SELECT JOG SPEED 2 selected JOG SPEED 1 selected
3 = OCL ENABLE OCL enabled OCL disabled
DIG IN 1 (P.495)
Only available if the I/O Expansion kit is installed.
Shows the state of digital input 1 (terminal 59 on the I/O Expansion board).
The input is ON when +24 VDC is applied for more than 20 ms. It is OFF when 0 VDC is applied.
Digital inputs 1 and 2 (terminals 59 and 60) are used to select which, if any, PRESET SPEED is used as
the speed reference for the speed/voltage control loop. See PRESET SPEED 1, 2, and 3 for more
information.
Parameter Range: ON,
OFF
OIM Menu Path(s):
Input/Output - Digital I/O
Refer also to Parameters: PRESET SPEED 1 (P.117),
PRESET SPEED 2 (P.118)
PRESET SPEED 3 (P.119)
