FlexPak 3000 Main Menu
~
Network
Communications
NETWORK KIT (P.796)
NETW TYPE & VERSION (P.909)
NETW COMM STATUS (P.908)
NETW DROP NUMBER (P.900)
NETW COMM LOSS SELECT (P.901)
NETW CONNECT TYPE (P.910)
AMX NETW REF SELECT (P.911)
NETW OUT REG 1 SELECT (P.902)
NETW OUT REG 2 SELECT (P.903)
NETW OUT REG 3 SELECT (P.904)
NETW IN REG 1 (P.905)
NETW IN REG 2 (P.906)
NETW IN REG 3 (P.907)
NETWORK BAUD RATE (P.912)
DEVICENET POLL MSG (P.913)
Field
Standard/enhanced Field Supply
J20 FIELD LOSS DETECT (P.597)
FIELD ECONOMY ACTIVE (P.599)
FIELD ECONOMY DELAY (P.501)
ENHANCED FLD VOLT ADJ (P.500)
J21 FLD SUPPLY JUMPER (P.598)
Field Current Regulator
FLD CURRENT REGULATOR (P.586)
Field Loop Test Points
FIELD
REFERENCE
(P.590)
FIELD
FEEDBACK
(P.589)
FIELD ECONOMY ACTIVE (P.599)
FIELD
DELTA
(P.588)
Field Loop Tuning
FIELD REF REGISTER (P.513)
FIELD PI PROP GAIN (P.514)
FIELD PI LEAD FREQ (P.515)
FLD WEAKEN THRESHOLD (P.518)
IR
COMPENSATION
(P.206)
IFLD WEAKEN PROP GAIN (P.519)
IFLD WEAKEN LEAD FREQ (P.520)
Field Loop Configure
FIELD ECONOMY REF (P.511)
FIELD ECONOMY DELAY (P.501)
FIELD LOSS THRESHOLD (P.512)
FIELD AUTO WEAKEN (P.517)
FIELD DELTA HIGH LIM (P.587)
Field Loop Feedback Scaling
MOTOR HOT FLD AMPS (P.510)
FLD FEEDBACK GAIN ADJ (P.516)
FIELD
FEEDBACK
(P.589)
