DRIVE SETUP AND ADJUSTMENT
49’1340 e FlexPak 3000 4-9
Current Minor Loop(CML)

CML Test Points

 CML Tuning*

 Self Tuning Setup*
 
Self Tuning
 
CML Feedback Scaling*

 Three-Phase A-C Line*

 SCR Diagnostics*
 Armature Phase Fire Test
Outer Control Loop (OCL)

 OCL Test Points
 OCL Tuning
 OCL Configure
Network Communications
Input/Output

 Meter Outputs
 Analog I/O*
 Digital I/O*
 Frequency I/O*
 Level Detectors*
Drive Information*
 Correct Scaling Jumper Positions*
Field*
 Standard/enhanced Field Supply
 Field Current Regulator
 Field Loop Test Points
 Field Loop Tuning
 Field Loop Configure
 Field Loop Feedback Scaling
Operator Interface*

 Memory Operations
 
Memory Save
  Memory Restore
  Restore Defaults

 Reset Clock

 Define User Units
 Define Speed Units
 Define Load Units
 Define Outer Control Loop Units
An asterisk (*) in these paths indicates that a parameter or a parameter list exists when ENTER is pressed at that
menu selection. The * is not actually displayed when the menu selection is displayed on the OIM.
Refer to Appendices B and C for information regarding the menu access path(s) for individual parameters.
Appendix B contains an alphabetized list of input parameters with their associated default values, code No.,
description and the menu path for access. Appendix C contains an alphabetized list of output parameters with a
description, code No. and the menu path for access.
