FlexPak 3000 Main Menu
~
Three Phase AC Line
NOMINAL AC LINE FREQ (P.306)
NOMINAL AC LINE VOLTS (P.307)
AC LINE PERIOD (P.393)
AC LINE VOLTAGE (P.392)
PLL MAXIMUM ERROR (P.308)
SCR Diagnostics
OPEN SCR SENSITIVITY (P.600)
OPEN SCR TRIP THRESH (P.601)
Armature Phase Fire Test
PHASE FIRE TEST DELTA (P.309)
PHASE FIRE TST BRIDGE (P.310)
ARMATURE DELTA (P.399)
CML FEEDBACK (P.397)
ARMATURE VOLTAGE (P.289)
Outer Control Loop (OCL)
OCL Test Points
OCL ENABLE (P.849)
OCL REFERENCE (P.845)
OCL RAMP OUTPUT (P.846)
OCL FEEDBACK (P.847)
OCL OUTPUT (P.848)
OCL Tuning
OCL PI PROP GAIN (P.808)
OCL PI LEAD FREQ (P.809)
OCL PI POSITIVE LIMIT (P.810)
OCL PI NEGATIVE LIMIT (P.811)
OCL LEADLAG LOW FREQ (P.806)
OCL LEADLAG RATIO (P.807)
OCL TRIM RANGE (P.812)
OCL REF RAMP TIME (P.802)
OCL REF ROUNDING (P.803)
OCL Configure
OCL REFERENCE SELECT (P.800)
OCL REF REGISTER (P.801)
OCL FEEDBACK SELECT (P.804)
OCL LEADLAG SELECT (P.805)
