DRIVE SETUP AND ADJUSTMENT
49’1340 e FlexPak 3000 4-7
4.6 Powering Up the Drive
Apply A-C power to the drive after the Power Off Inspection, Motor Ground Check and Drive Setup
procedures are completed.
During initial power-up, the drive displays the following three screens on the OIM.
WELCOME TO THE FLEXPAK 3000
DIGITAL D-C DRIVE.
(c) Copyright Reliance Electric
Industrial Company 1994
Keypad Version: xxx
Running keypad/display diagnostics
Please wait.
Link initialization in progress.
Reading Regulator data.
Please wait.
FlexPak 3000 Main Menu
" Quick Start
Drive Reference
Speed/Voltage Loop (SPD)
# Current Minor Loop (CML)
!!
PROGRAM TERMBLK MANUAL FORWARD
4.7 OIM Screen Contrast Adjustment
This function can be enabled at any program menu level but not at parameter value entry screens.
To enable the contrast adjustment function, press the right arrow key. The Contrast Adjustment
Screen appears as:
Contrast Adjustment
A B C D E F G H I J K L M N O P Q R S
Press RIGHT/LEFT to INC/DEC contrast.
$$
$$
Fault
Alarm
Interlock OK
Drive Ready
Running
Current Limit
Torque Limit
PROGRAM KEYPAD MANUAL FORWARD
The left arrow key decreases the contrast setting and the right arrow key increases the contrast
setting.
•
Press ENTER to accept the new contrast setting.
Press CANCEL to return to the previous menu screen.
•
A memory save must be performed in order to save the new contrast setting to non-volatile
memory.
