APPENDIX F
49'1340 e FlexPak 3000 F-3
FlexPak 3000 Main Menu
Drive Reference Configure
JOG SPEED (P.012)
ANLG AUTO SIGNAL TYPE (P.100)
STOP MODE SELECT (P.114)
STOP SPEED THRESHOLD (P.113)
AUTO REFERENCE SELECT (P.103)
MANUAL REF SELECT (P.106)
JOG OFF DELAY TIME (P.121)
PRESET SPEED 1 (P.117)
PRESET SPEED 2 (P.118)
PRESET SPEED 3 (P.119)
MOP RESET ENABLE (P.116)
Drive Reference Scaling
ANLG AUTO ZERO ADJ (P.102)
ANLG AUTO GAIN ADJ (P.101)
ANALOG AUTO REFERENCE (P.188)
ANLG MAN REF ZERO ADJ (P.105)
ANLG MAN REF GAIN ADJ (P.104)
ANALOG MAN REFERENCE (P.192)
ANALOG MAN TRIM REF (P.194)
Speed/Voltage Loop (SPD)
Speed/Voltage Loop (SPD) Test Points
SPD LOOP REFERENCE (P.295)
SPD LOOP FEEDBACK (P.296)
SPD LOOP ERROR (P.297)
SPD LOOP LAG OUTPUT (P.298)
SPD LOOP OUTPUT (P.299)
CURRENT COMPOUND TP (P.293)
ARMATURE VOLTAGE(P.289)
IR COMPENSATION TP (P.290)
ANALOG TACH FEEDBACK (P.291)
PULSE TACH FEEDBACK (P.292)
Speed/Voltage Loop (SPD) Tuning
SPD LOOP PI PROP GAIN (P.211)
SPD LOOP PI LEAD FREQ (P.212)
Self Tuning Setup
SELF TUNE BRIDGE (P.220)
SELF TUNE FIELD RANGE (P.218)
SELF TUNE STABILITY (P.219)
Self Tuning
POSITIVE CURRENT LIM (P.005)
NEGATIVE CURRENT LIM (P.006)
CURRENT COMPOUNDING (P.209)
SPD LEADLAG SELECT (P.216)
SPD LEADLAG LOW FREQ (P.214)
SPD LEADLAG RATIO (P.213)
SPD LOOP LAG BYPASS (P.217)
SPD LOOP LAG FREQ (P.215)
IR COMPENSATION (P.206)
INERTIA COMP SELECT (P.221)
NORMALIZED INERTIA (P.222)
POS CURRENT LIM SEL (P.223)
NEG CURRENT LIM SEL (P.224)
