APPENDIX C
FlexPak 3000 49’1340 e C-4
DIG IN 2 (P.496)
Only available if the I/O Expansion kit is installed.
Shows the state of digital input 2 (terminal 60 on the I/O Expansion board).
The input is ON when +24 VDC is applied for more than 20 ms. It is OFF when 0 VDC is applied.
Digital inputs 1 and 2 (terminals 59 and 60) are used to select which, if any, preset speed is used as the
speed reference for the speed/voltage control loop. See PRESET SPEED 1, 2, and 3 for more
information.
Parameter Range: ON, OFF
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: PRESET SPEED 1 (P.117),
PRESET SPEED 2 (P.118)
PRESET SPEED 3 (P.119)
DIG IN 3 (P.497)
Only available if the I/O Expansion kit is installed.
State of digital input 3 (terminal 62 on the I/O Expansion board), which is the MOP decrement input. The
input is ON when +24 VDC is applied for more than 20 ms. It is OFF when 0 VDC is applied.
See MOP ACCEL TIME for discussion and block diagram.
Parameter Range: ON, OFF
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: DIG IN 4 (P.498),
MOP ACCEL TIME (P.115)
DIG IN 4 (P.498)
Only available if the I/O Expansion Kit is installed.
State of digital input 4 (terminal 63 on the I/O Expansion board), which is the MOP increment input.
The input is ON when +24 VDC is applied for more than 20 ms. It is OFF when 0 VDC is applied.
See MOP ACCEL TIME for discussion and block diagram.
Parameter Range: ON, OFF
OIM Menu Path(s): Input/Output - Digital I/O
Refer also to Parameters: DIG IN 3 (P.497),
MOP ACCEL TIME (P.115)
DIG IN 5 (P.499)
Only available if the I/O Expansion Kit is installed.
State of Outer Control Loop enable input (terminal 64 on the I/O Expansion board).
The input is ON when +24 VDC is applied for more than 20 ms. It is OFF when 0 VDC is applied.
Parameter Range: ON, OFF
OIM Menu Path(s): Input/Output - Digital I/O
DRAW PERCENTAGE OUT (P.196)
Determined by the selected trim reference signal and TRIM RANGE value. DRAW PERCENTAGE is
used as a multiplier in the proportional trim mode for accelerate and decelerate rates. It is also used to
generate the TRIM OUTPUT value.
OIM Menu Path(s): Drive Reference - Drive Reference Test Points
