APPENDIX C
FlexPak 3000 49’1340 e C-6
I/O EXPANSION KIT (P.797)
Indicates whether or not the I/O Expansion kit is installed in the drive and if it has passed diagnostics.
If the I/O Expansion Kit has failed diagnostics, the drive is not operable (the armature cannot become
active).
Parameter Range: NOT INSTALLED,
INSTALLED
FAILED
DIAGS
OIM Menu Path(s): Input/Output - Frequency I/O, Input/Output - Analog I/O
Input/Output - Digital I/O, Drive Information
IR COMPENSATION TP (P.290)
An output testpoint that represents the level of IR COMPENSATION being used by the drive.
This parameter only has meaning if the selected drive feedback is set to armature voltage.
OIM Menu Path(s): Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Test Points
J11 ANLG TACH VLT SCL (P.792)
Position in which to set J11 hardware jumper based on the values of TOP SPEED
and ANALOG TACH V/1000.
OIM Menu Path(s): Drive Information - Correct Scaling Jumper Positions Quick Start
Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Feedback
J14 ANLG TACH VLT RNG (P.793)
Position in which to set J14 hardware jumper based on the values of TOP SPEED
and ANALOG TACH V/1000.
OIM Menu Path(s): Drive Information - Correct Scaling Jumper Positions Quick Start
Speed/Voltage Loop (SPD) - Speed/Voltage Loop (SPD) Feedback
J15 REGULATOR TYPE (P.799)
Indicates the position of hardware jumper J15 REGULATOR TYPE, which selects the type of regulator:
SPEED/VOLTAGE or CURRENT/TORQUE. This jumper is only read at power-up.
OIM Menu Path(s): Drive Information, Current Minor Loop (CML) - CML Test Points
J18 ARM I FB RESISTOR (P.395)
Indicates the required burden resistor position to scale armature current feedback based on the values
of CT TURNS RATIO, MAXIMUM CURRENT and MOTOR RATED ARM AMPS.
OIM Menu Path(s): Drive Information - Correct Scaling Jumper Positions
Current Minor Loop (CML) - CML Feedback Scaling Quick Start
Refer also to Parameters: CT TURNS RATIO (P.010),
MAXIMUM CURRENT (P.007)
MOTOR RATED ARM AMPS (P.008)
