62 Rockwell Automation Publication 2080-UM002F-EN-E - December 2013
Chapter 7 Motion Control with PTO and PWM
Use the Micro800 Motion Control Feature
The Micro800 motion control feature has the following elements. New users
need to have a basic understanding of the function of each element to effectively
use the feature.
ATTENTION: To use the Micro800 Motion feature effectively, users need
to have a basic understanding of the following:
•
PTO components and parameters
See
Use the Micro800 Motion Control Feature on page 62 for a general
overview of Motion components and their relationships.
•
Programming and working with elements in the Connected Components
Workbench software
The user needs to have a working knowledge of ladder diagram,
structured text, or function block diagram programming to be able to work
with motion function blocks, variables, and axis configuration
parameters.
ATTENTION: To learn more about Connected Components Workbench
and detailed descriptions of the variables for the Motion Function Blocks,
you can refer to Connected Components Workbench Online Help that
comes with your Connected Components Workbench installation.
IMPORTANT The PTO function can only be used with the controller’s embedded I/O. It
cannot be used with expansion I/O modules.
Components of Motion Control
Element Description Page
Pulse Train Outputs Consists of one pulse output and
one direction output. A standard
interface to control a servo or
stepper drive. • Input and Output Signals on
page 64
