Specifications Appendix A
Micro850 48-Point Controllers
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
10V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4:
±2 kV @ 5 kHz on power ports
±2 kV @ 5 kHz on signal ports
±1 kV @ 5 kHz on communication ports
Surge transient immunity
IEC 61000-4-5:
±1 kV line-line(DM) and ±2 kV line-earth(CM) on power ports
±1 kV line-line(DM) and ±2 kV line-earth(CM) on signal ports
±1 kV line-earth(CM) on communication ports
Conducted RF immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Isolated AC Inputs (2080-LC50-24QWB, 2080-LC50-24QVB, 2080-LC50-24QBB)
(Inputs 0…7)
Attribute
Value
On-state voltage, nom
12/24V AC @ 50/60 Hz
Off-state voltage, min
4V AC @ 50/60Hz
Operating frequency, nom
50/60 Hz
Environmental Specifications
Attribute
Value
General Specifications – 2080-LC50-48AWB, 2080-LC50-48QWB, 2080-LC50-48QVB, 2080-LC50-48QBB
Attribute
2080-LC50-48AWB
2080-LC50-48QWB
2080-LC50-48QVB
2080-LC50-48QBB
Number of I/O
48 (28 inputs, 20 outputs)
Dimensions
HxWxD
90 x 238 x 80 mm
(3.54 x 9.37 x 3.15 in.)
Shipping weight, approx.
0.725 kg (1.60 lb)
Wire size
0.2…2.5 mm
2
(24…12 AWG) solid copper wire or
0.2…2.5 mm
2
(24…12 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
2 – on communication ports
Wire type
Use Copper Conductors only
Terminal screw torque
0.4…0.5 Nm (3.5…4.4 lb-in.)
(using a 0.6 x 3.5 mm flat-blade screwdriver)
Input circuit type
120V AC
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type
Relay
24V DC sink (standard and
high-speed)
24V DC source (standard
and high-speed)
