Micro830 16-point controllers – Rockwell Automation 2080-LC50 Micro830 and Micro850 Programmable Controllers User Manual User Manual
Page 169

Rockwell Automation Publication 2080-UM002F-EN-E - December 2013
153
Specifications Appendix A
Micro830 16-Point Controllers
General – 2080-LC30-16AWB, 2080-LC30-16QWB, 2080-LC30-16QVB
Attribute
2080-LC30-16AWB
2080-LC30-16QWB
2080-LC30-16QVB
Number of I/O
16 (10 inputs, 6 outputs)
Dimensions
HxWxD
90 x 100 x 80 mm
(3.54 x 3.94 x 3.15 in.)
Shipping weight, approx.
0.302 kg (0.666 lb)
Wire size
0.14…2.5 mm
2
(26…14 AWG) solid copper wire or
0.14…1.5 mm
2
(26…14 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type
Use Copper Conductors only
Terminal screw torque
0.6 Nm (4.4 lb-in.) max
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type
120V AC
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type
Relay
12/24V DC sink transistor (standard
and high-speed)
Event input interrupt
support
Yes
Power consumption
7.88 W
Power supply voltage range
20.4…26.4V DC Class 2
I/O rating
Input 120V AC, 16 mA
Output 2 A, 240V AC, general use
Input 24V DC, 8.8 mA
Output 2 A, 240V AC, general use
Input 24V DC, 8.8 mA
Output 24V DC, 1 A per point
(Surrounding air temperature 30 °C)
24V DC, 0.3 A per point (Surrounding
air temperature 65 °C)
Isolation voltage
250V (continuous), Reinforced Insulation Type, Outputs to Aux and Network,
Inputs to Outputs
2080-LC30-16AWB: Type tested for 60 s @ 3250V DC I/O to Aux and Network,
Inputs to Outputs
2080-LC30-16QWB: Type tested for 60 s @ 720V DC, Inputs to Aux and
Network, 3250V DC Outputs to Aux and Network, Inputs to Outputs
50V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs
Type tested for 60s @ 720 V DC, I/O
to Aux and Network, Inputs to
Outputs
Pilot duty rating
C300, R150
–
Insulation stripping length
7 mm (0.28 in.)
Enclosure type rating
Meets IP20
North American temp code
T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication
.
