Rockwell Automation Publication 2080-UM002F-EN-E - December 2013 29
Chapter
4
Wire Your Controller
This chapter provides information on the Micro830 and Micro850 controller
wiring requirements. It includes the following sections:
Wiring Requirements and
Recommendation
• Allow for at least 50 mm (2 in.) between I/O wiring ducts or terminal
strips and the controller.
Topic Page
Wiring Requirements and Recommendation 29
Use Surge Suppressors 30
Recommended Surge Suppressors 32
Grounding the Controller 33
Wiring Diagrams 33
Controller I/O Wiring 36
Minimize Electrical Noise 37
Analog Channel Wiring Guidelines 37
Minimize Electrical Noise on Analog Channels 37
Grounding Your Analog Cable 38
Wiring Examples 38
Embedded Serial Port Wiring 39
WARNING: Before you install and wire any device, disconnect power to
the controller system.
WARNING: Calculate the maximum possible current in each power and
common wire. Observe all electrical codes dictating the maximum
current allowable for each wire size. Current above the maximum ratings
may cause wiring to overheat, which can cause damage.
United States Only: If the controller is installed within a potentially
hazardous environment, all wiring must comply with the requirements
stated in the National Electrical Code 501-10 (b).
