Use the High-Speed Counter and Programmable Limit Switch Chapter 8
Micro830/Micro850 24-point Controller HSC Input Wiring Mapping
Modes of Operation
Input 0 (HSC0)
Input 2 (HSC1)
Input 4 (HSC2)
Input 6 (HSC3)
Input 1 (HSC0)
Input 3 (HSC1)
Input 5 (HSC2)
Input 7 (HSC3)
Input 2 (HSC0)
Input 6 (HSC2)
Input 3 (HSC0)
Input 7 (HSC2)
Mode Value in User
Program
Counter with Internal Direction
(mode 1a)
Count Up
Not Used
0
Counter with Internal
Direction, External Reset and
Hold (mode 1b)
Count Up
Not Used
Reset
Hold
1
Counter with External
Direction (mode 2a)
Count Up/Down
Direction
Not Used
2
Counter with External
Direction, Reset and Hold
(mode 2b)
Count Up/Down
Direction
Reset
Hold
3
Two Input Counter (mode 3a)
Count Up
Count Down
Not Used
4
Two Input Counter with
External Reset and Hold (mode
3b)
Count Up
Count Down
Reset
Hold
5
Quadrature Counter (mode 4a) A Type input
B Type input
Not Used
6
Quadrature Counter with
External Reset and Hold (mode
4b)
A Type input
B Type input
Z Type Reset
Hold
7
Quadrature X4 Counter
(mode 5a)
A Type input
B Type input
Not Used
8
Quadrature X4 Counter with
External Reset and Hold
A Type input
B Type input
Z Type Reset
Hold
9
Micro830/Micro850 48-point Controller HSC Input Wiring Mapping
Modes of Operation
Input 0 (HSC0)
Input 2 (HSC1)
Input 4 (HSC2)
Input 6 (HSC3)
Input 8 (HSC4)
Input 10 (HSC5)
Input 1 (HSC0)
Input 3 (HSC1)
Input 5 (HSC2)
Input 7 (HSC3)
Input 9 (HSC4)
Input 11 (HSC5)
Input 2 (HSC0)
Input 6 (HSC2)
Input 10 (HSC4)
Input 3 (HSC0)
Input 7 (HSC2)
Input 11 (HSC4)
Mode Value in User
Program
Counter with Internal Direction
(mode 1a)
Count Up
Not Used
0
Counter with Internal
Direction, External Reset and
Hold (mode 1b)
Count Up
Not Used
Reset
Hold
1
Counter with External
Direction (mode 2a)
Count Up/Down
Direction
Not Used
2
Counter with External
Direction, Reset and Hold
(mode 2b)
Count Up/Down
Direction
Reset
Hold
3
Two Input Counter (mode 3a)
Count Up
Count Down
Not Used
4
Two Input Counter with
External Reset and Hold (mode
3b)
Count Up
Count Down
Reset
Hold
5
Quadrature Counter (mode 4a) A Type input
B Type input
Not Used
6
