Additional Redundant Server Procedures 6-15
b. Select the Station type as Static Station.
c. Enter >1< as the Static Station Number and click Advanced.
d. Check the Auxiliary setup file checkbox.
e. Click Browse and navigate to:
C:\Honeywell\Client\Station\defaultb.stn and click Open.
15. Click Save.
16. Click Yes to save changes.
17. Highlight Default and click Connect.
18. Click Cancel at the Unable to connect prompt, if applicable.
19. If you have redundant LANs, you must repeat Step 1 through Step 18 to
set up files for the second LAN using the name or IP address of the
SERVERA and SERVERB nodes specified in the Hosts file for the
second LAN
.
Navigate in Knowledge Builder to Server and Client Configuration
Guide
⇒
Configuring and Monitoring a Redundant Server System
⇒
Configuring
Stations for Server Redundancy
⇒
Dual Network Configuration for more
information.
20. Click Station
⇒
Exit.
21. Click Yes to exit Station.
Setting Up Station on
SERVERB 1. On SERVERB, click Start
⇒
Programs
⇒
ProcessLogix Server
⇒
Station.
2. Click Cancel at the Unable to connect prompt, if applicable.
3. Click Station
⇒
Connect to call up the Station Connect dialog box.
4. Click New Connection.
5. On the Connection tab, make these entries to have the Station point to
SERVERB (PLX1B):
a. In the Server field, enter or Browse to the Secondary Server name,
SERVERB.
b. Select the Station type as Static Station.
IMPORTANT You must indicate the full path to the .stn file.
