Rockwell Automation 1757-SWKIT5000 ProcessLogix R500.1 Installation and Upgrade Guide User Manual
Page 163

Publication 1757-IN500A-EN-P - September 2002
Additional Redundant Server Procedures 6-7
c. Close the ProcessLogix Server dialog box.
3. Are you using a dual network (LAN) data link with your redundant
Servers?
• If the answer is Yes, go to Step 4.
• If the answer is No, go to Step 10.
4. Use Windows Explorer to locate the redun.hdw file in this directory
path:
C:\Honeywell\server\user
5. Double-click the redun.hdw file to open it in Notepad.
6. Modify the file to include the following entries for dual data links.
This is only required if you have redundant LANs.
DEL LNK00
ADD LNK00 NETWORK_LINK
DEL LNK01
ADD LNK01 NETWORK_LINK
The default file definition is for a single network (LAN) data link.
7. Click File
⇒
Save to save your changes to the file.
8. Close Notepad.
9. Close Windows Explorer.
10. Click Start
⇒
Run.
11. Enter this command:
>cmd<
and click OK to open the DOS window.
IMPORTANT
For information about the required operator actions for the
setup of fast failover, navigate in Knowledge Builder to
Server and Client Configuration Guide
⇒
Configuring and
Monitoring a Redundant Server System
⇒
Server Redundancy Fast
Failover Configuration topic for HOSTS file and redundant
hardware build details.
