Appendix A PowerMonitor 1000 Data Tables
Table 29 - Power Results Parameters
CSP File No.
F22
CIP Instance
15
No. of Elements
17
No. of Words
34
Data Type
Float
Data Access
Read
Table 30 - Power Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
0
30301-2
L1 True Power Factor -100.0…+100.0
•
•
Percent ratio between power and
apparent power. The value is signed
to (+) leading and (-) lagging.
1
30303-4
L2 True Power Factor -100.0…+100.0
•
•
2
30305-6
L3 True Power Factor -100.0…+100.0
•
•
3
30307-8
3 Phase True Power
Factor
-100.0…+100.0
•
•
4
30309-10
L1 kWatts
+/- 0.000…9,999,999
•
•
Line 1 kWatts
5
30311-12
L2 kWatts
+/- 0.000…9,999,999
•
•
Line 2 kWatts
6
30313-14
L3 kWatts
+/- 0.000…9,999,999
•
•
Line 3 kWatts
7
30315-16
Total kWatts
+/- 0.000…9,999,999
•
•
Total kWatts
8
30317-18
L1 kVAR
+/- 0.000…9,999,999
•
•
Line 1 kVAR
9
30319-20
L2 kVAR
+/- 0.000…9,999,999
•
•
Line 2 kVAR
10
30321-22
L3 kVAR
+/- 0.000…9,999,999
•
•
Line 3 kVAR
11
30323-24
Total kVAR
+/- 0.000…9,999,999
•
•
Total kVAR
12
30325-26
L1 kVA
0.000…9,999,999
•
•
Line 1 kVA
13
30327-28
L2 kVA
0.000…9,999,999
•
•
Line 2 kVA
14
30329-30
L3 kVA
0.000…9,999,999
•
•
Line 3 kVA
15
30331-32
Total kVA
0.000…9,999,999
•
•
Total kVA
16
30333-34
Metering Iteration
0…9,999,999
•
•
Increments by 1 for each new
metering calculation.
IMPORTANT
Only total power values are returned in delta wiring modes.
Zeroes are returned for individual phase values.
