Appendix A PowerMonitor 1000 Data Tables
Table 61 - Parameters for Configurable Table
Parameter No.
Parameter Name
Description
0
None
No Parameter.
1
Date: Year
Refer to
table.
2
Date: Month
3
Date: Day
4
Time: Hour
5
Time: Minute
6
Time: Seconds
7
Time: Hundredths
8
Status Input States
Refer to
9
Output Word
10
Wiring Status
Refer to
table.
11
Voltage Input Missing
12
Voltage Input Inverted
13
Current Input Missing
14
Current Input Inverted
15
Voltage Rotation
16
Current Rotation
17
Voltage Phase 1 Angle
18
Voltage Phase 1 Magnitude
19
Voltage Phase 2 Angle
20
Voltage Phase 2 Magnitude
21
Voltage Phase 3 Angle
22
Voltage Phase 3 Magnitude
23
Current Phase 1 Angle
24
Current Phase 1 Magnitude
25
Current Phase 2 Angle
26
Current Phase 2 Magnitude
27
Current Phase 3 Angle
28
Current Phase 3 Magnitude
29
L1 Current
Volts, Amps, Frequency Results
30
L2 Current
31
L3 Current
32
Average Current
33
L1-N Volts
