90 Rockwell Automation Publication 1408-UM001D-EN-P - September 2013
Appendix A PowerMonitor 1000 Data Tables
4 30109-10 Current Input
Inverted
-1…123 • • • • • Reports on all three phases.
-1 = Test not run.
0 = Test passed.
1 = Phase 1 inverted
2 = Phase 2 inverted
3 = Phase 3 inverted
12 = Phase 1 and 2 inverted
13 = Phase 1 and 3 inverted
23 = Phase 2 and 3 inverted
123 = All phases inverted
5 30111-12 Voltage Rotation -1…132 • • • • • Reports on all three phases. The
reported sequence represents each
phase. Example: 123 = Phase 1 then
phase 2 then phase 3
-1 = Test not run
4 = Invalid rotation
1…132 designating phase and
rotation.
6 30113-14 Current Rotation -1…321 • • • • • Reports on all three phases. The
reported sequence represents each
phase. Example: 123 = Phase 1 then
phase 2 then phase 3
-1 = Test not run
4 = Invalid rotation
1…321 designating phase and
rotation.
7 30115-16 Voltage Phase 1
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel. Should always be 0
degrees for voltage phase 1.
8 30117-18 Voltage Phase 1
Magnitude
Volts 0…9,999,999 • • • Shows the present magnitude of this
phase.
9 30119-20 Voltage Phase 2
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel.
10 30121-22 Voltage Phase 2
Magnitude
Volts 0…9,999,999 • • • Shows the present magnitude of this
phase.
11 30123-24 Voltage Phase 3
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel.
12 30125-26 Voltage Phase 3
Magnitude
Volts 0…9,999,999 • • • Shows the present magnitude of this
phase.
13 30127-28 Current Phase 1
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel.
14 30129-30 Current Phase 1
Magnitude
Amperes 0…9,999,999 • • • Shows the present magnitude of this
phase.
15 30131-32 Current Phase 2
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel.
16 30133-34 Current Phase 2
Magnitude
Amperes 0…9,999,999 • • • Shows the present magnitude of this
phase.
17 30135-36 Current Phase 3
Angle
Degrees 0…359.99 • • • Shows the present phase angle of
this channel.
Table 26 - Wiring Diagnostics Results
Element
No.
Modbus
Address
Element Name Units Range
TR1 TR2 EM1 EM2 EM3
Description
