PowerMonitor 1000 Data Tables Appendix A
Table 55 - Catalog Number and WIN Parameters
CSP File No.
N34
CIP Instance
27
Applies to
All models
No. of Elements
19
No. of Words
19
Data Type
Integer
Data Access
Read
Table 56 - Catalog Number and WIN
Element
No.
Modbus
Address
Element Name
Range
Description
0
31501
Catalog # text char pair #1
0…32767
Contains the product number (example: 1408-EM3A-485A, but with out the
dashes). A read of this table returns the catalog # as 4 integers: each integer
contains a character pair. For each character pair, character 1=integer/256
and character 2 = remainder of integer/256.
1
31502
Catalog # text char pair #2
2
31503
Catalog # text char pair #3
3
31504
Catalog # text char pair #4
4
31505
Catalog # text char pair #4
5
31506
Catalog # text char pair #4
6
31507
Reserved
0
Reserved for future use.
7
31508
Hardware Series
0…25
Indicates the product series letter.
For example, 0=A, 1=B,
8
31509
WIN # text char pair #1
0…32767
Contains the product WIN(Warranty Identification Number). This is the same
alpha-numeric string that can be found on the master module label (example:
21AW0AT5HO). 5 integers each contains two characters as displayed by the
Catalog parameter method.
9
31510
WIN # text char pair #2
10
31511
WIN# text char pair #3
11
31512
WIN# text char pair #4
12
31513
WIN# text char pair #5
13
31514
Reserved
0
Reserved for future use.
14
31515
Reserved
0
Reserved for future use.
15
31516
Original Model
0…10
This number represents the catalog number type.
0 = TR1
1 = TR2
2 = EM1
3 = EM2
4 = EM3
5 through 10 = Reserved
16
31517
Current Model
0…10
The current model of the product. This can be the same as the original model
(if no upgrades have been performed).
17
31518
Reserved
0
Reserved for future use.
18
31519
Reserved
0
Reserved for future use.
