PowerMonitor 1000 Data Tables Appendix A
18
30137-38
Current Phase 3
Magnitude
Amperes
0…9,999,999
•
•
•
Shows the present magnitude of this
phase.
19
30139-40
Degrees out of
range
0…360
•
•
•
•
•
When Status = 5, how many degrees
out of range.
20
30141-42
Reserved
0
•
•
•
•
•
Reserved for future use
Table 26 - Wiring Diagnostics Results
Element
No.
Modbus
Address
Element Name
Units
Range
TR1
TR2
EM1
EM2
EM3
Description
Table 27 - Volts, Amps, Frequency Results Parameters
CSP File No.
F21
CIP Instance
14
No. of Elements
16
No. of Words
32
Data Type
Float
Data Access
Read
Table 28 - Volts, Amps, Frequency Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM
1
EM
2
EM
3
Description
0
30201-2
L1 Current
0.000…9,999,999
•
•
•
Phase 1 scaled RMS Current
1
30203-4
L2 Current
0.000…9,999,999
•
•
•
Phase 2 scaled RMS Current
2
30205-6
L3 Current
0.000…9,999,999
•
•
•
Phase 3 scaled RMS Current
3
30207-8
Average Current
0.000…9,999,999
•
•
•
Average RMS Current
4
30209-10
L1-N Volts
0.000…9,999,999
•
•
•
Phase 1 scaled RMS Voltage
5
30211-12
L2-N Volts
0.000…9,999,999
•
•
•
Phase 2 scaled RMS Voltage
6
30213-14
L3-N Volts
0.000…9,999,999
•
•
•
Phase 3 scaled RMS Voltage
7
30215-16
Average L-N Volts
0.000…9,999,999
•
•
•
Averaged RMS Voltage
8
30217-18
L1-L2 Volts
0.000…9,999,999
•
•
•
Line 1 to Line 2 Volts
9
30219-20
L2-L3 Volts
0.000…9,999,999
•
•
•
Line 2 to Line 3 Volts
10
30221-22
L3-L1 Volts
0.000…9,999,999
•
•
•
Line 3 to Line 1 Volts
11
30223-24
Average L-L Volts
0.000…9,999,999
•
•
•
Average Line to Line Volts
12
30225-26
Frequency
40.0 Hz…70.0 Hz
•
•
•
Last frequency reading.
13
30227-28
Percent Current
Unbalance
0.0…100.0
•
•
•
Percent maximum deviation from Ave.
/ Ave.
14
30229-30
Percent Voltage
Unbalance
0.0…100.0
•
•
•
Percent Maximum deviation from Ave.
/ Ave.
15
30231-32
Metering Iteration
0…9,999,999
•
•
•
Increments by 1 for each new
metering calculation.
