Rockwell Automation Publication 1408-UM001D-EN-P - September 2013 83
PowerMonitor 1000 Data Tables Appendix A
Table 18 - Command Table
Element
No.
Modbus
Address
Element Name Default
Value
Range
TR1 TR2 EM
1
EM
2
EM
3
Description
0 40601-2 Password 0 0…9999 • • • • • When writing the complete table this
parameter allows the input data to be
accepted. When writing a single parameter
the separate password table should be used.
Returns -1 on a read.
1 40603-4 Command Word 1 0 0…32 • • • • • These commands can be sent to the power
monitor. When using the optional elements
the command table must be sent complete
with all elements present. If the single
password table is used to gain access to
configuration items then the command can
be sent alone without optional settings. The
command options are:
0 = No Action
1 = Set kWh Register
2 = Set kVARh Register
3 = Set kVAh Register
4 = Clear All Energy Registers
5 = Set Status 1 Count
6 = Set Status 2 Count
7 = Clear Energy Log
8 = Force KYZ Output On
9 = Force KYZ Output Off
10 = Remove Force from KYZ
11 = Restore Factory Defaults
12 = Perform Wiring Diagnostics
13 = Reset power monitor System
14…32 = Reserved
If a command is received that is not
supported by your catalog number the
command will be ignored.
2 40605-6 Command Word 2 0 0…32 • • • • • 0 = No Action
1 = Clear Min/Max Records
2 = Store and clear current Load Factor
Record
3 = Clear Load Factor Log
4 = Store and clear current TOU Record
5 = Clear TOU Log
6 = Clear Error Log command
7 = Troubleshooting Mode Enable
8…32 = Reserved.
If a command is received that is not
supported by your catalog number the
command will be ignored.
3 40607-8 Clear Single Min/
Max Records
0 0…35
0…31
0…19
• • • When setting the Min/Max Clear bit this
value can be sent to specify a single
parameter. If clearing all values this is not
required.
EM3 = 0…35
TR2 = 0…31
TR1 = 0…19
0=Clear All Parameters
1= Clear the 1st Min/Max Record
2= Clear the 2nd Min/Max Record
…
35=Clear the 35th Min/Max Record
