Rockwell Automation Publication 1408-UM001D-EN-P - September 2013

81

PowerMonitor 1000 Data Tables Appendix A

4

40505

Off Peak Days

65

0…127

This bit map field selects the off peak days.

OFF-PEAK days have only one rate for billing.
Bit0= Sunday

Bit1= Monday

Bit2= Tuesday

Bit3= Wednesday

Bit4= Thursday

Bit5= Friday

Bit6= Saturday

Saturday and Sunday are default Off Peak

days.

5

40506

MID Peak AM

Hours

1792

0…

4095

This bit map selects any AM hours that are

designated as MID Peak. Example: The hours

from 8 AM to 11AM is designated as bit 8

through bit 10 = 1792d.
Bit0= 12 AM…1 AM

Bit1= 1 AM…2 AM

Bit2= 2 AM…3 AM

Bit11= 11AM…12 AM

Default is 8 AM…11 AM

6

40507

MID Peak PM

Hours

120

0…

4095

This bit map selects any PM hours that are

designated as MID Peak. Example: The hours

from 3 PM to 7 PM is designated as bit 3

through bit 6 = 120d.
Bit0= 12 PM…1 PM

Bit1= 1 PM…2 PM

Bit2= 2 PM…3 PM

Bit11= 11PM…12 PM

Default is 3 PM…7 PM

7

40508

ON Peak AM

Hours

2048

0…

4095

This bit map selects any AM hours that are

designated as ON Peak. Example: The hours

from 11AM to 12 PM is designated as bit 11

= 2048d.
Bit0= 12 AM…1 AM

Bit1= 1 AM…2 AM

Bit2= 2 AM…3 AM

Bit11= 11AM…12 AM

Default is 11AM

8

40509

ON Peak PM

hours

7

0…4095

This bit map selects any PM hours that are

designated as ON Peak. Example: The hours

from 12 PM to 3 PM is designated as bit 0

through bit 2 = 7d
Bit0= 12 PM…1 PM

Bit1= 1 PM…2 PM

Bit2= 2 PM…3 PM

Bit11= 11PM…12 PM

Default is 12 PM…3 PM

Table 16 - Log Configuration

Element

No.

Modbus

Address

Element Name

Default

Value

Range

TR1

TR2

EM

1

EM

2

EM

3

Description
