PowerMonitor 1000 Data Tables Appendix A

Table 25 - Wiring Diagnostics Results Parameters

CSP File No.

F20

CIP Instance

13

No. of Elements

21

No. of Words

42

Data Type

Float

Data Access

Read

Table 26 - Wiring Diagnostics Results

Element

No.

Modbus

Address

Element Name

Units

Range

TR

1

TR

2

EM

1

EM

2

EM

3

Description

0

30101-2

Wiring Status

0…5

This is the overall status of the wiring

diagnostic test.

0 = Pass

1 = Failed

2 = Input Level Low

3 = Disabled

4 = Waiting Command

5 = Out of range

1

30103-4

Voltage Input

Missing

-1…123

Reports on all three phases.

-1 = Test not run.

0 = Test passed.

1 = Phase 1 missing

2 = Phase 2 missing

3 = Phase 3 missing

12 = Phase 1 and 2 missing

13 = Phase 1 and 3 missing

23 = Phase 2 and 3 missing

123 = All phases missing

2

30105-6

Voltage Input

Inverted

-1…123

Reports on all three phases.

-1 = Test not run.

0 = Test passed.

1 = Phase 1 inverted

2 = Phase 2 inverted

3 = Phase 3 inverted

12 = Phase 1 and 2 inverted

13 = Phase 1 and 3 inverted

23 = Phase 2 and 3 inverted

123 = All phases inverted

3

30107-8

Current Input

Missing

-1…123

Reports on all three phases.

-1 = Test not run.

0 = Test passed.

1 = Phase 1 missing

2 = Phase 2 missing

3 = Phase 3 missing

12 = Phase 1 and 2 missing

13 = Phase 1 and 3 missing

23 = Phase 2 and 3 missing

123 = All phases missing
