126

Rockwell Automation Publication 1408-UM001D-EN-P - September 2013

Appendix A Specifications

Table 63 - Input and Output Specifications - 1408-TR1A-xxx, 1408-TR2A-xxx,

1408-EM1A-xxx, 1408-EM2A-xxx, 1408-EM3A-xxx

Attribute

Value

Control power

85…264V AC 47…63 Hz
125…250V DC
4 VA max

Voltage sense inputs: V1,

V2, V3

Input impedance: 5 M  min
Input current: 2 mA max

Current sense inputs: I1,

I2, I3

Overload withstand:

15 A continuous, 200 A for 1/2 s

Burden: 0.05V A

Impedance: 0.002 

Max crest factor at 5 A is 3.0

Starting current: 5 mA

Status inputs

Contact closure (internal 24V DC)

KYZ output

80 mA at 240V AC / 300V DC

Table 64 - Environmental Specifications - 1408-TR1A-xxx, 1408-TR2A-xxx,

1408-EM1A-xxx, 1408-EM2A-xxx, 1408-EM3A-xxx

Attribute

Value

Dielectric

withstand

Control power

2500V

Voltage inputs

2500V

Current inputs

2500V

Status inputs

2500V

KYZ output

2500V

Terminal blocks

0.34…2.5 mm

2

(22…14 AWG), 75 °C (167 °F) min copper wire only

Recommended torque 0.8 N

·

m (7 lb

·

in)

Operating

temperature

-10…60 °C (14…140 °F)

Storage

temperature

-40…85 °C (-40…185 °F)

Humidity

5…95%, noncondensing

Vibration

2.0 g 10…500 Hz

Shock

30 g peak each axis (operating)

50 g peak each axis (nonoperating)
