Rockwell Automation Publication 1408-UM001D-EN-P - September 2013

107

PowerMonitor 1000 Data Tables Appendix A

Table 51 - Time of Use Log Results - Reactive Energy and Demand Parameters

CSP File No.

F32

CIP Instance

25

No. of Elements

12

No. of Words

24

Data Type

Float

Data Access

Read

Table 52 - Time of Use Log Results - Reactive Energy and Demand

Element

No.

Modbus

Address

Element Name

Range

TR1

TR2

EM1

EM2

EM3

Description

0

31301-2

Record Number

1…13

The record number of the log. Record 0 is always

the current record before being logged.

1

31303-4

Time Stamp Start

Date (yy/mm/dd)

-

The Date this record was started.

2

31305-6

Time Stamp End

Date (yy/mm/dd)

-

The Date this record was ended.

3

31307-8

Off Peak GVARH

Net

+/- 0…

9,999,999

Net Off peak giga VAR hours

4

31309-10

Off Peak kVARh

Net

+/- 0.000…

999,999

Net Off Peak kilo VAR hours

5

31311-12

Off Peak kVAR

Demand

+/- 0.000…

9,999,999

Off Peak Demand for kilo VAR

6

31313-14

Mid Peak GVARH

Net

+/- 0…

9,999,999

Net Mid Peak giga VAR hours

7

31315-16

Mid Peak kVARh

Net

+/- 0.000…

999,999

Net Mid Peak kilo VAR hours

8

31317-18

Mid Peak kVAR

Demand

+/- 0.000…

9,999,999

Mid Peak Demand for kilo VAR

9

31319-20

On Peak GVARH

Net

+/- 0.000…

9,999,999

Net On Peak giga VAR hours

10

31321-22

On Peak kVARh

Net

+/- 0…

999,999

Net On Peak kilo VAR hours

11

31323-24

On Peak kVAR

Demand

+/- 0.000…

9,999,999

On Peak Demand for kilo VAR
