13 Parameter reference
13.6 Monitor panel (integrated/external)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13.6 Monitor panel (integrated/external)
This chapter lists all parameters of the monitor panel (panel controller) and the parameters of an
external, optional panel in numerically ascending order.
The parameters are available depending on the panel variant.
C0420
C0421
C0422
C0423
Parameter | Name:
C0420 | Panel: Width
Data type: UNSIGNED_16
Index: 24155
d
= 5E5B
h
Horizontal resolution of the panel
Display range
(min. value | unit | max. value)
160 2400
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C0421 | Panel: Height
Data type: UNSIGNED_16
Index: 24154
d
= 5E5A
h
Vertical resolution of the panel
Display range
(min. value | unit | max. value)
100 2000
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C0422 | Dimout: Actual value
Data type: UNSIGNED_8
Index: 24153
d
= 5E59
h
Enter the actual brightness value of the display. The numerical value ranges from the
• Maximum = 0 and the
• Minimum = 63
Setting range (min. value | unit | max. value) Lenze setting
0 63 0
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C0423 | Brightness: Upper limit
Data type: UNSIGNED_8
Index: 24152
d
= 5E58
h
Enter the maximum brightness value of the display. The numerical value ranges from the
• Maximum = 0 and the
• Minimum = 63
Setting range (min. value | unit | max. value) Lenze setting
0 63 0
 Read access  Write access  CINH  PLC-STOP  No transfer
