10 Device replacement - replacing the controller (in the event of
service)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

How to install and connect a new controller:
1. Insert the SD card of the removed controller into the new one.
2. Connect bus connections and other connections.
3. Connect the current supply of the controller.
4. If I/O modules (I/O system 1000) have to be connected to the controller:
Plug in electronic module of the first system 1000 (if available).
5. Switch on voltage supply.
The Controller will start when the data is automatically updated.

Tip!
The progress of the update process can be ...
• ... seen in the logbook of the controller. Click the Logbook button to display the
logbook of the controller in the »WebConfig«.
• identified by means of the Status LEDs of the Controllers ( 80) on the Controller.

Note!
Prevent voltage failure
In the event of a voltage failure during the update, the process will be stopped.
During the next system start the update process will automatically restart.
Free memory location is required on the memory card
The controllers require an SD card for operation.
• For a successful data update, the memory card of the Controllers must be provided
with a sufficient amount of free memory space.
• Guide value for the size of a backup file:
size of the data to be updated + 1 MB
