13 Parameter reference
13.9 Communication cards: optional interface
183
Lenze · Controller | Parameter setting & programming · Reference Manual · DMS 1.5 EN · 04/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C1121
C1122
C1130
C1131
Parameter | Name:
C1121 | Sync master: Interface index
Data type: UNSIGNED_32
Index: 23454
d
= 5B9E
h
Note: Restart the L-force Controller after changing this parameter!
Setting range
(min. value | unit | max. value) Lenze setting
4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C1122 | Baud rate
Data type: UNSIGNED_32
Index: 23453
d
= 5B9D
h
Baud rate of the CAN interface. The value is assigned from a selection list.
Selection list
(Lenze setting printed in bold)
7 5
6 10
5 20
3 50
8 100
2 125
1 250
0 500
4 1000
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C1130 | Tx PDO counter
Data type: UNSIGNED_32
Index: 23445
d
= 5B95
h
PDO counter for sent CAN messages
Display range
(min. value | unit | max. value)
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C1131 | Rx PDO counter
Data type: UNSIGNED_32
Index: 23444
d
= 5B94
h
PDO counter for received CAN messages
Display range
(min. value | unit | max. value)
 Read access  Write access  CINH  PLC-STOP  No transfer
