13 Parameter reference
13.5 EtherCAT
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C286/7
C286/8
C286/9
C286/10
C286/11
Parameter | Name:
C286/7 | ECAT counter: Tx frames
Data type: UNSIGNED_32
Index: 24289.7
d
=
0x5EE1.0x07
h
Number of sent frames
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/8 | ECAT counter: Rx frames
Data type: UNSIGNED_32
Index: 24289.8
d
=
0x5EE1.0x08
h
Number of received frames
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/9 | ECAT counter: Lost frames
Data type: UNSIGNED_32
Index: 24289.9
d
=
0x5EE1.0x09
h
Number of lost frames
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/10 | ECAT counter: cyclical frames
Data type: UNSIGNED_32
Index: 24289.10
d
=
0x5EE1.0x0A
h
Number of cyclical frames
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/11 | ECAT counter: cyclical datagrams
Data type: UNSIGNED_32
Index: 24289.11
d
=
0x5EE1.0x0B
h
Number of cyclical datagrams
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
