13 Parameter reference
13.5 EtherCAT
165
Lenze · Controller | Parameter setting & programming · Reference Manual · DMS 1.5 EN · 04/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C282/3
C286/3
C286/4
C286/5
C286/6
Parameter | Name:
C282/3 | - ECAT DC: Current deviation
Data type: INTEGER_32
Index: 24293.3
d
=
0x5EE5.0x03
h
Current maximum deviation of the distributed clocks of all devices in nanoseconds.
Display range
(min. value | unit | max. value)
-2147483647 ns 2147483647
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/3 | ECAT bus: No. of slaves
Data type: UNSIGNED_32
Index: 24289.3
d
=
0x5EE1.0x03
h
Number of slaves connected to the fieldbus
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/4 | ECATBus: No. of slaves with DC
Data type: UNSIGNED_32
Index: 24289.4
d
=
0x5EE1.0x04
h
Number of slaves connected to the fieldbus and supported by distributed clocks
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/5 | ECAT config.: No. of slaves
Data type: UNSIGNED_32
Index: 24289.5
d
=
0x5EE1.0x05
h
Number of slaves configured in the master configuration file
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C286/6 | ECAT config.: No. of mailbox slaves
Data type: UNSIGNED_32
Index: 24289.6
d
=
0x5EE1.0x06
h
Number of mailbox slaves configured in the master configuration file
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer
