ITEM PART NO. QTY. DESCRIPTION
1 --- - See “ASD Fan Assembly (2010 Production and on)” on page P83
2 GD19658-01
G11142 1
2 Hose, 6" x 12"
T-Bolt Clamp 6¼"
3 GB0448
GR1777 1
1 ASD Manifold
Hose Barb, ⅛" Male NPT To 3/16" Barb
4 GA13776
GD19639
G11091
G10390
G10071 1
1
2
2
2 ASD Manifold Bracket
U-Bolt, 4½" x ⅜"-16
Serrated Flange Nut, ⅜"-16
Carriage Bolt, ½"-13 x 1"
Serrated Flange Nut, ½"-13
5 GA13777
GD19639
G11091
G10390
G10071 1
1
2
2
2 ASD Manifold Bracket
U-Bolt, 4½" x ⅜"-16
Serrated Flange Nut, ⅜"-16
Carriage Bolt, ½"-13 x 1"
Serrated Flange Nut, ½"-13
6 GD19696
---
G11135
G11385
G10621
G10108
G10001 1
-
2
2
2
4
2
ASD Block Mount
See “ASD Valve Block” on page P185
Hex Head Cap Screw, ¼"-20 X 3¾"
Flat Washer, ¼" SAE
Serrated Flange Nut, ¼"-20
Lock Nut, ⅜"-16
Hex Head Cap Screw, ⅜"-16 x 1"
7 GA13631
G10017
G10228
GD19856
G10007
G10107
G10003 1
4
4
1
2
2
2 EdgeVac Fan Mount
Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Fan Mount Tap Block
Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Nut, ⅝"-11
Hex Head Cap Screw, ⅜"-16 x 1½"
8 GA10917
GD19225
G6801-12
G10961
G10620 1
2
3
4
4 Hydraulic Oil Cooler
Cooler Mount Bracket
Elbow W/O-Ring, 90°, 11/16"-12 Male JIC To O-Ring
Flanged Whiz Lock Screw, 5/16"-18 x ¾", No Serration
Serrated Flange Nut, 5/16"-18
9 GD16038
GD19129
GD16037
G6400-12
GR1467
G6502-12
G10023
G10227
G11385 1
1
1
1
-
1
2
2
2
Filter Head
Oil Filter Mount
Oil Filter, 10 Micron
Connector, W/O-Ring, 11/16"-12 Male JIC To O-Ring
O-Ring
Swivel Elbow, 45°, 11/16"-12 Male JIC To Female
Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
Flat Washer, ¼" SAE
10 G11188 4 T-Bolt Clamp, 5¼"
11 GD19659-01 2 Black Hose, 4½" I.D. x 39"
ASD Manifolds and Distribution Hoses (2010 Production and
on)
Model 3660 M0217-02
Rev. 7/11 P94
