ASD Scale Package
ITEM PART NO. QTY. DESCRIPTION
1 GA14135 6 Load Cell
2 GA14136 1 Scale Module
3 GA14129 1 Power Cable
4 GA14133 1 ASD Scale Display
5 GD26264 1 Scale Module Mounting
6 G10857 2 Hex Head Cap Screw, ¼"-20 x 1¼"
7 G10023 2 Hex Head Cap Screw, ¼"-20 x ¾"
8 G10621 4 Serrated Flange Nut, ¼"-20
9 GA12403 1 Mounting Bracket Assembly, Includes: (2) Mounting Brackets, (2) Connector Halves,
(1) Compression Spring, (1) Tension Knob, (1) ¼"-20 x 1¾" Hex Head Cap Screw,
(1) ¼" Plastic Washer, (1) ¼" Steel Washer
10 GD20282
G11284 1
2 U-Bolt, #10-32
Serrated Flange Nut, #10-32
11 G11216 2 Phillips Pan Head Machine Screw, No. 10-32 x ½", Stainless Steel
Model 3660 M0217-02
Rev. 6/13 P106
