Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 179)

Tongue Cylinder
ITEM PART NO. QTY. DESCRIPTION
1 A13937
A13953 1
1 Barrel (Non-Stock Item), 12 Row
Barrel (Non-Stock Item), 16 Row
2 GA13935
GA8859 1
1 Rod Assembly, 12 Row
Rod Assembly, 16 Row
3 GD12104 1 Ring, 1¾"
4 *D12200 1 Wiper, 1¾"
5 *D12253 1 U-Cup
6 GD11984 1 Gland
7 G6400-08-04
GR1465 1
-
Connector W/O-Ring, ¾"-16 Male JIC To 7/16"-20 O-Ring
O-Ring
8 *D12203 1 Back-Up Ring, No. 334
9 *D12202 1 O-Ring, No. 334
10 GD7147 1 Spacer
11 *D12204 1 O-Ring, No. 218
12 GD11970 1 Piston
13 *D12278 1 T-Seal
14 *D12047 1 Wear Ring
15 GD27237 1 Nylon Lock Nut, 1¼"-12, Grade 8
16 G6408-08
GR1037 1
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
17 G304-C-8 1 Cap Nut, ¾-16
18 G10328 1 Hex Head Cap Screw, ⅜"-16 x ⅝"
19 G10229 1 Lock Washer, ⅜"
20 GD12597 1 Bracket
21 G2700-08 1 Bulkhead Tube Union, ¾"-16 Male JIC
22 GA13939
GA8979 1
1 Hydraulic Tube Assembly, 62⅞", 12 Row
Hydraulic Tube Assembly, 9211/16", 16 Row
A GA13938
GA13954 -
- Cylinder Complete, 3" x 54" (Part Number Stamped On Barrel), 12 Row
Cylinder Complete, 3" x 84" (Part Number Stamped On Barrel), 16 Row
B GR1519 - Seal Kit, Includes: (2) O-Rings, (1) BU Ring, (1) Wiper, (1) U-Cup, (1) T-Seal, (1)
Wear Ring
*Part of seal kit, item can not be purchased individually.
Model 3660 M0217-02
Rev. 6/14 P176
