ITEM PART NO. QTY. DESCRIPTION
1 G10801
G11389
G10228
G10102 2
2
2
2 Carriage Bolt, ½"-13 x 2¼"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
2 GA13617 2 Idler Arm
3 GD19393 1 Bushing
4 GA7154 2 Sprocket W/Bearing, 18 Tooth
5 GA5090
GD5752
GD5753 1
1
1 Tire And Rim Assembly (Specify Brand*)
Inner Tube
Tire, 4.10" x 6" (Specify Brand*)
6 G10302
G11386
G10232
G10106 12
12
12
12 Carriage Bolt, 5/16"-18 x ⅞"
Flat Washer, 5/16" SAE
Lock Washer, 5/16"
Hex Nut, 5/16"-18
7 GA13614 1 Fertilizer Wheel Arm
8 G10233 8 Machine Bushing, 1½" x 1/32", 10 Gauge
9 GA9846
G10302
G11386
G10232
G10106 2
6
6
6
6 Flanged Bearing, ⅞" Hex Bore
Carriage Bolt, 5/16"-18 x ⅞"
Flat Washer, 5/16" SAE
Lock Washer, 5/16"
Hex Nut, 5/16"-18
10 GD6825-9.875
G10602 1
2 Hex Shaft, ⅞" x 9⅞"
Spring Pin, ¼" x 1½"
11 GA7180 1 Sprocket, 40 Tooth
12 GD7889 1 Bushing, 1" O.D. x 9/16" I.D. x 7/16" Long
13 GA13619 1 Fertilizer Pump Mount
14 GA9357 4 Bearing, ⅞" Hex, Single Lip
15 G3400-01 8 Flangette
16 GD16598
G10230
G10104 1
2
2 U-Bolt, 4" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
17 G10003
G11387
G10229
G10101 1
1
1
1 Hex Head Cap Screw, ⅜"-16 x 1½"
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
18 GD6825-13
G10602 1
2 Hex Shaft, ⅞" x 13"
Spring Pin, ¼" x 1½"
19 --- - See “Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)” on page P233
20 GA13620 1 Wrench Bracket
21 GA2068 2 Spring W/Plug
22 G10053 2 Hex Head Cap Screw, ½"-13 x 2½"
23 G11389 2 Flat Washer, ½" SAE
24 G10041 1 Hex Head Cap Screw, 5/16"-18 x 2"
25 GB0218 2 Bushing, 21/32" I.D. x ⅞" O.D. x 19/32" Long
26 GD19401 1 Spring Mount
27 G10689
G11391
G10107 2
2
2 Carriage Bolt, ⅝"-11 x 2"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
28 GD5857 2 Spring
29 GD2558 1 Lynch Pin, ¼"
30 GA5111 2 Sprocket, 26 Tooth
31 G3310-104 1 Chain, No. 40, 104 Pitch Including Connector Link
32 G3310-58 1 Chain, No. 40, 58 Pitch Including Connector Link
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied. Different brand tires may have different diameters. Change
in tire brand may affect rates. Field checks are recommended after any change in tires.
Liquid Fertilizer Piston Pump Mount and Ground Drive Wheel
Model 3660 M0217-02
