Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 211)

ITEM PART NO. QTY. DESCRIPTION
1 G10686
G11091 4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Serrated Flange Nut, ⅜"-16
2 GD18118 2 Shaft Sensor Mount
3 GR1415 1 Rotation Sensor
4 GR1414 1 Actuator
5 GD18168 2 Mount
6 G10757
G10243
G10758 2
2
2 Pan Head Screw, No. 10-32 x 1¼"
Washer, No. 10 SAE
Hex Nut, No. 10-32
7 GD11474 2 Cover
8 G10927
G10931
G10928 2
2
2 Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
9 GD19274 1 Module Mount
10 GD19275 1 Module Mount Brace
11 G10031
G10620 1
1 Hex Head Cap Screw, 5/16"-18 x 1¾"
Serrated Flange Nut, 5/16"-18
12 G10018
G10620 1
1 Hex Head Cap Screw, 5/16"-18 x ⅝"
Serrated Flange Nut, 5/16"-18
13 G10002
G10622 2
2 Hex Head Cap Screw, ⅜"-16 x ¾"
Serrated Flange Nut, ⅜"-16
14 GA12538 1 Planter Monitor Module
15 G11386 1 Flat Washer, 5/16" SAE
16 G10133
G10620 2
2 Hex Head Cap Screw, 5/16"-18 x 1½"
Serrated Flange Nut, 5/16"-18
17 GA12563 1 Module Cover Assembly W/Lock Clamps
18 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
19 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
20 G1K248 - 3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings,
(9) Pin Contacts, (9) Seals
G1K362 - 3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings,
(9) Pin Contacts, (9) Seals
21 G1K252 - 3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings,
(9) Socket Contacts, (9) Seals
G1K363 - 3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings,
(9) Socket Contacts, (9) Seals
22 GD11089 - Sealing Plug
23 GR0594 - Brush
24 GA13981
GA13980
GD11993 -
-
- Planter Harness W/Dust Caps, 16 Row (20 Connectors)
Planter Harness W/Dust Caps, 12 Row (18 Connectors)
Dust Cap
25 GA19961
GA19960 -
- Seed Tube W/Computerized Sensor
Seed Tube (With Holes For Sensor Installation)
26 GA7859 1 Magnetic Distance Sensor Adapter (Analog To Digital)
27 GA14116 - Sending Unit W/¼” Tubing And Harness
28 GA13397 - Extension Harness, 6”
29 GA7858 - Radar Distance Sensor W/20' Cable
30 GA8026 - Radar Sensor Pipe/Mounting Bracket Package
31 G1K323 - 4-Pin Connector Kit W/Female Housing, Includes: (4) Pins, (1) Cable Clamp
32 GR1736 - Hose Barb, ⅛" Male NPT To Barb
33 GA12812 - Hall Effect Adapter
34 GA14116 - Sending Unit With ¼" Tubing And Harness
35 GA16923 - Dickey John Adapter Cable
Planter Monitor Module (PMM)
Model 3660 M0217-02
Rev. 6/14 P208
TM
