Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 137)

Airline Fittings and Hoses
ITEM PART NO. QTY. DESCRIPTION
1 GA13519 1 Compressor Cable
2 --- - See "Air Compressor, Dual Solenoid Assembly, Tubing, and Fittings" on page P137
3 GD17141 2 Connector, ¼" Male NPT
4 GA11992 2 Shutoff Valve, ¼" NPT
5 GA11989 1 Valve Stem, ⅛" NPT
6 GD17144 1 Reducer, ⅛" Male To ¼" Female
7 GD19088 2 Tee, ¼" Male NPT To ¼" Female NPT
8 GD19172 1 Quick Disconnect Hose Coupler
9 GD18010 2 Tee, ⅜" Tube Union
10 GD17150-13 1 Nylon Tubing, ⅜" O.D. x 15"
11 GD18015 12 Tee, ¼" Press On
12 GD17151-01 2 Nylon Tubing, ¼" O.D. x 52'
13 --- - See "Air Clutch, Pull Row Unit" on page P5
14 --- - See "Clutch Valve Assembly" on page P188
15 GA14846 1 High Pressure Sensor (0-120 PSI)
16 GA12812 1 Hall Effect Adapter
17 GD17151-06 1 Nylon Tubing, ¼" O.D. x 1½'
18 GD18796 1 Reducer, ⅜" To ¼"
19 GD17156 1 Plug, ¼" NPT
Model 3660 M0217-02
Rev. 7/11 P134
