ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 G10536 1 Detent Pin, ½" x 2½" Grip
2 G10597 1 Square Head Set Screw, ⅝"-11 x 2¼"
3 G10503 1 Hex Jam Nut, ⅝"-11, Grade 2
4 GA5719 1 Mounting Bracket
5 GD7889 6 Bushing, 1" O.D. x 9∕16" I.D. x 7∕16" Long
6 G10039
G11389
G10111 2
2
2 Hex Head Cap Screw, ½"-13 x 1¾"
Flat Washer, ½" SAE
Lock Nut, ½"-13
7 GD7890 2 Link
8 GA5715 1 Anchor
9 G10017
G11389
G10111 4
2
4 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Nut, ½"-13
10 GA5892 1 Leveler
11 GD8266 2 Blade
12 G10303
G11386
G10109 6
4
6 Carriage Bolt, 5∕16"-18 x 1"
Flat Washer, 5∕16" SAE
Lock Nut, 5∕16"-18, Grade 8
13 G10585
G11389
G10111 1
2
1 Hex Head Cap Screw, ½"-13 x 3¼"
Flat Washer, ½" SAE
Lock Nut, ½"-13
Row Unit Mounted Bed Leveler
Model 3660 M0217-02
Rev. 7/11 P40
