P162 – Kinze 3660 Lift and Rotate Planter Rev. 6/14 User Manual
Page 165
ITEM
PART NO.
QTY.
DESCRIPTION
1
A8775
G6408-08
GR1037
1
2
-
Barrell
(Non-Stock Item)
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
2
GD27233
1
Nylon Lock Nut, ¾"-16, Grade 8
3
*D12277
1
T-Seal
4
GD4632
1
Piston
5
*D12239
1
O-Ring, No. 016
6
*D12235
1
O-Ring, No. 326
7
*D12236
1
Back-Up Ring
8
*D19250
1
U-Cup
9
*D19251
1
Wiper
10
GD5949
1
Gland
11
GD19662
1
Ring
12
GA8816
1
Rod Assembly
A
GA8818
-
Cylinder Complete, 2" x 8" (Part Number Stamped On Barrel)
B
GR1930
-
Seal Kit, Includes: (2) O-Rings, (1) Back-Up Ring, (1) U-Cup, (1) Wiper, (1) Seal
*Part of seal kit, item can not be purchased individually.
Wing Down Pressure Cylinder
Model 3660
M0217-02
Rev. 6/14
P162
TM
