Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 161)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA13719
G10844
G10045
G10168
G10228
G10102 1
1
1
2
2
2 See "Row Marker Spindle/Hub/Blade" on page P155
Carriage Bolt, ½"-13 x 3½"
Hex Head Cap Screw, ½"-13 x 4½"
Machine Bushing, ½", 7 Gauge
Lock Washer, ½"
Hex Nut, ½"-13
2 GD0453-02
GD0453-08
GD0453-11 1
-
-
Extension Tube, 40", 16 Row
Extension Tube, 65" (Even Row Only)
Extension Tube, 35", 12 Row
3 GD18540
G10004
G10108 1
2
2 Lock-up Bracket Chain
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
4 GA9145
G10004
G10108 1
2
2 Molded Stop, 6¼" Long
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
5 G10071
GD2721 2
1 Serrated Flange Nut, ½"-13
U-Bolt, 2" x 2" x ½"-13
6 GA13114
GA13994
GD10538-07
G10039
G10111
G10643 1
-
1
1
1
-
Arm, Third Stage, 16 Row
Arm, Third Stage, 12 Row
Sleeve, ¾" O.D. x ½" I.D. x .3∕5"
Hex Head Cap Screw, ½"-13 x 1¾"
Lock Nut, ½"-13
Grease Fitting, 45°, ¼"-28
7 GD18889
G10345
G10460 1
2
4 Pin, 1" x 9¼"
Machine Bushing, 1", 14 Gauge
Cotter Pin, ¼" x 2"
8 GD25189 1 Marker Link
9 GA13764 1 Linkage
10 GD3180-34
GB0218
G11391
G10006
G10107
G10036
G10107 1
2
4
2
2
1
1 Sleeve, ⅞" O.D. x ⅝" I.D. x 2"
Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
Flat Washer, ⅝" SAE
Hex Head Cap Screw, ⅝"-11 x 2¼"
Lock Nut, ⅝"-11
Hex Head Cap Screw, ⅝"-11 x 4"
Lock Nut, ⅝"-11
11 GA17400
GA17399 1
-
Marker Link, 113¼", 16 Row
Marker Link, 66 ¾", 12 Row
12 GD18815
G10159
G10460 1
2
1 Pin, 1¼" x 8.38"
Machine Bushing, 1¼", 10 Gauge
Cotter Pin, ¼" x 2"
13 GA17402
GA17401 1
-
Arm W/Grease Fitting, Second Stage, 16 Row
Arm W/Grease Fitting, Second Stage, 12 Row
14 GD21142
G11400
G10159
G10640
G10403
G11320 1
1
1
1
1
1 Marker Pin, 1¼" x 1153⁄64"
Retaining Ring, 1¼"
Washer, 1⅞"
Grease Fitting, ¼"-28
Hex Head Cap Screw, ¼"-20 x 2½"
Lock Nut, ¼"-20, Grade B
15 GD19661-01
GD16418-02
G10033
G10111 1
2
1
1 Sleeve, ¾" O.D. x 33/64" I.D. x 2"
Sleeve, 1⅛" O.D. x 13∕16" I.D. x 7/16"
Hex Head Cap Screw, ½"-13 x 3½"
Lock Nut, ½"-13
Row Marker Assembly
Continued on the next page.
Model 3660 M0217-02
Rev. 6/14 P158
