Electrical components, P198 – Kinze 3660 Lift and Rotate Planter Rev. 6/14 User Manual
Page 201
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA3584
-
Ground Clamp
2
GA8328
-
4-Pin Female Connector Kit, Includes: (1) 4-Pin Female Housing, (4) Pin Contacts,
(4) Seals
3
GA6699
GA6700
GR1956
GR1957
GR1958
GR1208
1
1
-
-
-
-
Double Light Assembly
Double Light Assembly (Shown)
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Red Lens Kit, Includes: (1) Red Lens, (1) Gasket, and (3) Hex Head Cap Screws
Black Cover Kit, Includes: (1) Black Cover, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
4
GA6701
GR1956
1
-
Single Amber Light Assembly
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
5
GA13037
GA13976
-
-
Light Harness, 16 Row
Light Harness, 12 Row
6
GD8740
-
Socket Contact, No. 14
7
GD8741
-
Pin Contact, No. 14 (Package of 30)
8
GD8739
-
Sealing Plug, No. 12
9
GA6109
2
Connector W/Cable Clamp, 23 Pin Capacity
10
GA7862
2
Dust Cap W/Chain
11
GA7863
2
Dust Cap W/Chain
12
GA6108
2
Connector W/Cable Clamp, 23 Socket Capacity
13
G1K248
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
14
G1K320
-
2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
15
GD11089
-
Sealing Plug
16
GD6291
GD13348
GD22965
-
-
-
Insulated Clamp, ⅜"
Insulated Clamp, 11/16"
Insulated Clamp, ¼"
17
GD13310
1
Jumper, 7/16"
18
GA9481
G10996
-
-
Jumper Wire W/Fork Terminal, 13"
Fork Terminal
19
GA13752
-
Work Light Assembly
20
GA13750
-
Light Bracket
21
GD19613
-
Light Bracket Mount
22
GA13038
-
Work Light Harness
23
GA16388
GA17172
GA13035
GA13975
1
-
-
-
Planter Harness, 16 Row (2013 Production and on)
Planter Harness, 12 Row (2013 Production and on)
Planter Harness, 16 Row (Prior to 2013 Production)
Planter Harness, 12 Row (Prior to 2013 Production)
24
GA11736
1
Harness Extension W/Dust Caps, 180" (ASD and EdgeVac)
25
G8409X
-
3660 Control Box Bundle
26
G1K267
-
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp,
(3) Male Terminal Pins
27
G1K268
-
Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp,
(1) Lock Ring, (3) Female Terminal Pin
28
GA13036
GA16389
-
-
Tractor Harness (Prior to 2013 Production)
Tractor Harness (2013 Production and on)
29
GA8738
1
Control Box
30
GA14016
3
Switch, 3 Position Toggle, Momentary On-Off-Momentary On
31
GA2528
2
Switch, 3 Position Toggle, On-Off-On
32
GA14011
1
Backlit Front Panel
Electrical Components
Continued on the next page.
Model 3660
M0217-02
Rev. 6/13
P198
