Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 248)

Decals, Paint, and Miscellaneous
Part No.: G7100-262
Description: Reflective Decal, Amber, 1¾" x 9", Die-Cut
Quantity: 6 (used on 12 row; 8 (used on 16 row) (Located
on the hopper support of every other row unit
beginning on the L.H. side of the planter - Side-
racing in transport position) (Standard)
Part No.: G7100-258
Description: Reflective Decal, Red, 1½" x 9" Rectangular
Quantity: 1 (Per Outer Scraper - Located On Top)
Part No.: G7100-260
Description: Reflective Decal, Orange, 1½" x 9" Rectangular
Quantity: 1 (Per Outer Scraper - Located On Bottom)
With Even-Row Push Row Unit Option
G7100-258
G7100-260
G7100-259
Part No.: G7100-258
Description: Reflective Decal, Red, 1½" x 9" Rectangular
Quantity: 1 (Located On The Light Bracket On The L.H.
Side Of The Planter - Rear-Facing In Transport
Position)
Part No.: G7100-260
Description: Reflective Decal, Orange, 1½" x 9" Rectangular
Quantity: 1 (Located On The Light Bracket On The L.H.
Side Of The Planter - Rear-Facing In Transport
Position)
Part No.: G7100-259
Description: Reflective Decal, Amber, 1½" x 9", Rectangular
Quantity: 1 Used Located On The Front Of The Optional
Even-Row Push Row Unit - Side-Facing In
Transport Position)
TM
M0217-02 Model 3660
P245 Rev. 8/12
