Interplant Even Row Push Unit
ITEM PART NO. QTY. DESCRIPTION
1 GD18015 1 Tee, ¼" Press On
2 GD11279 1 Lid
3 GA9714 1 Seed Hopper, Reinforced
4 GD16598
G10230
G10104 1
6
4 U-Bolt, 4" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
5 GA13587 2 T-Bolt, ⅝"-11 x 5"
6 GD0914-30 1 Hex Shaft, ⅞" x 30" (No Holes)
7 G10233 1 Machine Bushing, 1½" x 1/32", 10 Gauge
8 --- - See “Interplant Push Row Unit, Air Clutch” on page P63
9 GA2180 1 Hanger Bearing, ⅞" Hex Bore
10 G10004
G11391
G10107 2
2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
11 G10013 2 Hex Head Cap Screw, ⅝"-11 x 3½"
12 G10338
G10620 2
2 Carriage Bolt, 5/16"-18 x 1¼"
Serrated Flange Nut, 5/16"-18
13 GD1109 2 Bushing, 41/64" I.D. x ⅞" O.D. x ¼" Long
14 GA6171 2 Bearing
15 GD1085 2 Rubber Tire, 1" x 12"
16 GD9120 4 Nylon Half Wheel
17 G10064 12 Hex Head Cap Screw, ¼"-20 x 1"
18 GA10151 1 Meter Drive Assembly Complete, 11/19 Tooth
19 GB0331 1 Clutch Adapter Plate
20 --- - See “Interplant Push Row Unit” on page P59
21 GA9130 1 Push Row Unit Light Bracket
22 G10001
G10229
G10101 2
4
4 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
23 GD6291 1 Insulated Clamp, ⅜"
24 --- - See “Planter Monitor Module (PMM)” on page P207
25 GD1719 1 Coupler, 4"
26 GA11331 3 Hex Lock Clamp Assembly
27 GD0453-03
GD0453-08 -
1
Extension Tube, 50", 12 Row
Extension Tube, 65", 16 Row
A GA6434 2 Rubber Closing Wheel Complete W/Bearing (Items 14-16)
Model 3660 M0217-02
Rev. 7/11 P66
