Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 141)

Air Compressor, Dual Solenoid Assembly, Tubing, and Fittings
ITEM PART NO. QTY. DESCRIPTION
1 G10022
G10227
G10103 2
2
2 Hex Head Cap Screw, ¼"-20 x ½"
Lock Washer, ¼"
Hex Nut, ¼"-20
2 GD18084 1 Regulator Bracket
3 GD19080 3 Elbow, ¼" x ⅛" NPT Swivel
4 GA12629 1 Mini Regulator W/Gauge
5 GD19087 2 Grommet, 1"
6 GA13398 1 Compressor Mount
7 GA12102 1 Air Compressor
8 G11327
G10243 4
4 Phillips Flat Head Machine Screw, No. 10-24 x ⅝", Stainless Steel
Washer, No. 10 SAE
9 G11297
G10251 2
2 Phillips Pan Head Machine Screw #8 - 32 x 1⅜", Stainless Steel
Hex Nut, No. 8-32
10 GD21274 1 Distribution Manifold
11 GR1778 1 Pressure Switch
12 GD19079 1 Plug, ⅛" NPT
13 GA13399
GD17151-06 1
1 Compressor Cover
Nylon Tubing, ¼" O.D. x 1.5'
14 GD17143 1 Swivel Elbow, ¼" NPT x ⅜"
15 GR1921
GR1951 1
1 Check Valve
Leader Hose without Check Valve
16 GA14127
GR1943
GA12404
GR1809
1
-
-
-
Filter Assembly (2010 production and on)
Filter (2010 production and on)
Filter Assembly (prior to 2010 production)
Filter (prior to 2010 production)
17 G10022
G10227 6
8 Hex Head Cap Screw, ¼"-20 x ½"
Lock Washer, ¼"
18 G10308
G11091 2
2 Carriage Bolt, ⅜"-16 x ¾"
Serrated Flange Nut, ⅜"-16
19 GD19089 1 Air Compressor Mount Bracket
20 GD19090
G11091 1
2 U-Bolt, 6" x ⅜-16
Serrated Flange Nut, ⅜"-16
21 G10004
G10229
G10101 1
1
1 Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
22 G11247 3 Slotted Pan Head Machine Screw, M4-0.7 x 8
23 GA11993
G10256
GR1952
GR1953 1
4
4
4 Block
Lock Washer, No. 8
Socket Head Cap Screw, #8-32 x 2"
O-Ring
24 GA11997 1 Breather, ¼" NPT
25 GD17143 1 Swivel Elbow, ¼" NPT x ⅜"
26 GD17156 2 Plug, ¼" NPT
27 G10040
G11385 2
2 Hex Head Cap Screw, ¼"-20 x 1¾"
Flat Washer, ¼" SAE
28 GA11994 2 Solenoid
29 GD17154 1 Connector, ¼" Male NPT
30 GD17141 2 Connector, ¼" Male NPT
31 GD18078 1 Female Cross, ¼" NPT
32 GA12104 1 Pressure Gauge, ¼" NPT
33 GA11992 1 Shutoff Valve, ¼" NPT
34 GA13169
GR1843 1
-
Tube Cutter W/Blade
Blade
Continued on the next page.
