ITEM PART NO. QTY. DESCRIPTION
1 G10583 2 Hex Head Cap Screw, 5∕16"-18 x 2 ¾"
2 G10232 5 Lock Washer, 5∕16"
3 GD18787 1 Rear Hydraulic Block Mount
4 G6400-08
GR1037 4
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
5 G6408-10
GR1466 2
-
Plug W/O-Ring, ⅞"-14 O-Ring
O-Ring
6 G6408-08
GR1037 2
-
Plug W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
7 G6801-LL-10
GR1466 1
-
X-Long Elbow W/O-Ring, 90°, ⅞"-14 Male JIC To O-Ring
O-Ring
8 G6801-12-10
GR1466 1
-
Elbow W/O-Ring, 90°. 1 1∕16"-12 Male JIC To ⅞"-14 O-Ring
O-Ring
9 GA13034 1 Reducing Valve/Pressure Relief
10 GD18509 1 Wing Down/Seed Rate Block
11 G6408-H06-0 3 Hex Socket Head Plug W/O-Ring, 9∕16"-18
12 GD19461 1 Block
13 G6801-LL-10
GR1466 1
-
X-Long Elbow W/O-Ring, 90°, ⅞"-14 Male JIC To O-Ring
O-Ring
14 G6801-10
GR1466 1
-
Elbow W/O-Ring, 90°, ⅞"-14 Male JIC To O-Ring
O-Ring
15 G6408-H06-0 5 Hex Socket Head Plug W/O-Ring, 9∕16"-18
16 G6408-08
GR1037 3
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
17 G6400-08
GR1037 10
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
18 GA13741 1 Terminal Strip Mount
19 GA9097 1 Terminal Strip W/Screws, No. 6, 14 Terminal
20 G11066 2 Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
21 G11067 2 Phillips Pan Head Machine Screw, No. 8-32 x ¾", Stainless Steel
22 GR0763
GR1445
GR0761 8
8
8 Cartridge
Coil
Special Hex Nut, ½"-20
23 GA3413 2 Flow Control Valve
24 GD13310
G10996 3
12
Jumper, 7∕16"
Fork Terminal
25 GD13348 1 Insulated Clamp, 11∕16"
26 GD13146 1 Valve Block Cover
27 G10977 2 Phillips Pan Head Machine Screw, No. 10-24 x ½", Stainless Steel
28 G10054M 1 Hex Head Cap Screw, 5∕16"-18 x ½"
29 G10106 1 Hex Nut, 5∕16"-18
30 GD8066-02 1 Sleeve, 1" Long
31 G10133 1 Hex Head Cap Screw, 5∕16"-18 x 1 ½"
32 GA3584 1 Ground Clamp
33 G10755 1 Hex Head Cap Screw, 5∕16"-18 x 3"
A GR2043 - Seal Kit (Reducing Valve/Pressure Relief)
Valve Blocks - Located on Rear Center Frame
Model 3660 M0217-02
Rev. 8/12 P182
