Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 207)

ITEM PART NO. QTY. DESCRIPTION
1 GA12536 1 Vision Loaner (Display Only)
2 GA12551 1 Display Cable
3 GA12562 1 Power Cable
4 GA12598 1 Seed Rate Power Cable
5 GD18176 3 Y-Splice Connector
6 GD18177 2 Terminator
7 GA12596 1 Radar Adapter Cable
8 GA12540 1 Power Control Relay
9 GA17544 1 Implement Cable
10 GA12538 1 Planter Monitor Module
11 GA12557 1 Planter Monitor Module Cable
12 GA12564 1 Seed Rate Control Module
13 GA12567 1 Can Extension Cable, 4" (Hydraulic Drive)
14 GA12566 1 Can Stub Cable, 6" (Hydraulic Drive)
15 GA12537 1 Clutch Control Module
16 GA12559 1 Can Extension Cable, 5''
17 GA12558 1 Can Stub Cable, 8''
18 GA12556 1 Seed Command Cable
19 GA16827 1 Implement Switch Extension Cable
20 --- - See “Parallel Arms, Mounting Support Plate, and Quick Adjustable Down Forces
Springs Option” on page P7
21 GA13204 1 Hall Effect Sensor
22 GA13048 1 Seed Rate Cable
23 --- - See “Valve Block - Located on R.H. Rear Center Frame (Mechanical)” on page P183
See “Valve Block - Located on R.H. Rear Center Frame (EdgeVac)” on page P184
24 GA12565 1 Encoder Module
25 --- - See “Clutch Valve Assembly” on page P188
26 --- - See “Airline Fittings and Hoses” on page P133
A G8266x - Vision Display Package (Items 1, 5, 6, 7, and 37)
Kinze Vision Display (Prior to 2013 Production)
Model 3660 M0217-02
Rev. 6/13 P204
TM
