ITEM PART NO. QTY. DESCRIPTION
1 *A12098
*A12099 1
-
Hose Assembly, ⅜" x 286", 12 Row
Hose Assembly, ⅜" x 346", 16 Row
2 *A12744
*A12738 2
-
Hose Assembly, ½" x 286", 12 Row
Hose Assembly, ½" x 346", 16 Row
3 *A12922
*A12911 2
-
Hose Assembly, ¾" x 286", 12 Row
Hose Assembly, ¾" x 346", 16 Row
4 G2700-12 2 Bulkhead Tube Union, 11/16"-12 Male JIC
5 G306-12 2 Lock Nut, 11/16"-12
6 G2700-10 2 Bulkhead Tube Union, ⅞"-14 Male JIC
7 G306-10 2 Lock Nut, ⅞"-14
8 G2700-06-06 1 Bulkhead Tube Union, 9/16"-18 Male JIC
9 G306-06 1 Lock Nut, 9/16"-18
10 *A12097 1 Hose Assembly, ⅜" x 246"
11 *A12715 2 Hose Assembly, ½" x 242"
12 *A12910 2 Hose Assembly, ¾" x 242"
13 *A3365 1 Hose Assembly, ¾" x 35"
14 *A1424 1 Hose Assembly, ½" x 30"
15 G6502-10 1 Swivel Elbow, 45°, ⅞"-14 Male JIC To Female
16 G6502-12 1 Swivel Elbow, 45°, 11/16"-12 Male JIC To Female
17 *A12014 1 Hose Assembly, ⅜" x 34"
18 *A3381 1 Hose Assembly, ¾" x 26"
19 *A12002 1 Hose Assembly, ⅜" x 32"
20 *A12736 1 Hose Assembly, ½" x 32"
21 G6602-06 1 Swivel Tee, 9/16"-18 JIC
22 GA15499
GD25522 -
- Special Pioneer Coupler, Zero Pressure Return
Hydraulic Tip Cover
*Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis. Call for quote.
ASD Fan Hydraulic Components (EdgeVac)
Model 3660 M0217-02
Rev. 7/11 P88
